BL218SSi
BL218SSi
Blaze Speakers
High-output sub-bass companion subwoofer housed in a tour-grade enclosure
Key Features
- 5000 W of stunning low-end response.
- Symmetrical dispersion pattern.
- Designed to satisfy the need for an extremely high SPL subbass loudspeaker system.
- Components have been selected solely for their performance.
- Utilizes two direct radiating 18-inch, 2500 W cone drivers in a tuned enclosure, which provides maximum output with minimal distortion and smooth extended low frequency response.
- The tour-tested 21-ply Baltic Birch highly braced enclosure and 24 mm thick baffle board construction provide unsurpassed rigidity and strength.
- Configurable as in cardioid, or end-fire arrays.
- Fully integrates with Blaze Audio’s PowerZone™ Connect amplifiers (3004 or higher)
Specifications
SKU | Color
FGM-888-011 (Black)
Frequency Response (+/- 10db)
18 Hz - 150 kHz
Frequency Response (+/- 3db)
25 Hz - 150 kHz
Power Handling (RMS)
5000W @4Ω
Enclosure
Baltic birch plywood, engineered plastics, and aluminum frame
Dimensions (WxHxD)
48.0" x 22.5" x 30.0" (1219.2mm x 571.5mm x 762.0mm)
Weight
285 lbs. (129.27kg)
Grille
14-gauge (1mm) perforated stainless steel powder-coated finish, black
Suspension Points
Internal bracket w/ threaded M-10 flying points (x 17)
Maximum SPL (Peak)
143 dB
Horizontal Nominal Dispersion (-6 dB)
Omni or Cardioid
