BL118SSi
BL118SSi
Blaze Speakers
High-output sub-bass companion subwoofer housed in a tour-grade enclosure
Key Features
- 2500 W of stunning low-end response.
- Symmetrical dispersion pattern.
- Designed to meet the demand for an extremely high SPL sub-bass loudspeaker system, with components carefully selected solely for their performance.
- Utilizes a direct radiating 18-inch, 2000 W cone driver in a tuned enclosure, which provides maximum output with minimal distortion and smooth extended low frequency response.
- Tour-tested 21-ply Baltic Birch highly braced enclosure and 24 mm thick baffle board construction.
- Configurable as in cardioid, or end-fire arrays.
- Fully integrates with Blaze Audio’s PowerZone™ Connect amplifiers (3004 or higher).
Specifications
SKU | Color
FGM-888-010 (Black)
Frequency Response (+/- 10db)
18 Hz - 150 kHz
Frequency Response (+/- 3db)
26 Hz - 150 kHz
Power Handling (RMS)
2500W @4Ω
Enclosure
Baltic birch plywood, engineered plastics, and aluminum frame
Dimensions (WxHxD)
28.0" x 22.5" x 30.0" (711.2mm x 571.5mm x 762.0mm)
Weight
135 lbs. (61.23kg)
Grille
14-gauge (1mm) perforated stainless steel powder-coated finish, black
Suspension Points
Internal bracket w/ threaded M-10 flying points (x 17)
Maximum SPL (Peak)
136 dB
Horizontal Nominal Dispersion (-6 dB)
Omni or Cardioid
