PowerZone 252
Amplifiers
Key Features
- Compact 1U half-rack form factor.
- Hybrid power distribution in both Lo-Z and Hi-Z.
- Flexible power sharing across output channels.
- Powered by Pascal UMAC Class-D technology.
- Eight-position DIP switch for operational configuration, including locking front panel gain cont
- GPIO interface for remote volume and standby.
- ErP and Energy Star compliant
- UL listed audio equipment
Specifications
SKU
UBX-888-015 (PowerZone 252), UBX-888-001 (PowerZone 252 UNI)
Dimensions (WxHxD)
8.66" x 1.73" x 10.35" (219.96mm x 43.94mm x 262.89mm)
Weight
4.19 lbs. (1.9kg)
Channel Configuration
Lo-Z: 2x 125W @4/8Ω Hi-Z: 1x 250W @70/100V Powersharing <= 1x 250W
Total System Power
250 W
Output Power @ 4 ohms
2 x 125 W
Output Power @ 8 ohms
2 x 125 W
Output Power @ 70V
2 x 125 W
Output Power @ 100V
2 x 125 W
Powersharing
<= 1 x 250 W
Power Consumption
75 W
Rack Units
1U Half Rack
