PowerZone Connect 254

Blaze Amplifiers

250 W DSP-enabled Class-D amplifier with 4 channels

PowerZone Connect 254

Key Features

  • Ultra-compact half rack form factor
  • Full-matrix DSP configuration via PowerZone™ Control web app (built-in)
  • Hybrid power distribution in both Lo-Z and Hi-Z
  • Powered by Pascal UMAC™ Class-D technology
  • Flexible power sharing across output channels
  • S/PDIF input/output
  • Configurable GPIO
  • ErP and Energy Star compliant
  • UL listed audio equipment
  • UREC™ universal power supply with PFC
  • 5 Year warranty

Specifications

SKU | Color

UBX-888-009 (PowerZone Connect 254), UBX-888-005 (PowerZone Connect 254 (UNI)), UBX-888-036 (PowerZone Connect 254 JPN)

Dimensions (WxHxD)

8.7" x 1.7" x 12.6" (220.98mm x 43.18mm x 320.04mm)

Weight

6.17 lbs. (2.8kg)

Channel Configuration

Lo-Z: 4x60W @4/8Ω Hi-Z: 2x 125W @70/100V Powersharing <= 1x 250W

Total System Power

250 W

Output Power @ 4 ohms

4 x 60 W

Output Power @ 8 ohms

4 x 60 W

Output Power @ 70V

2 x 125 W

Output Power @ 100V

2 x 125 W

Powersharing

<= 2 X 125 W

Power Consumption

75 W

Dante Compatibility

No

Copy All Specs
