PowerZone Connect 1502

Blaze Amplifiers

1500 W DSP-enabled Class-D amplifier with 2 channels

PowerZone Connect 1502

Key Features

  • Full rack 2U form factor
  • Full-matrix DSP configuration via PowerZone™ Control web app (built-in)
  • Hybrid power distribution in both Lo-Z and Hi-Z
  • Powered by Pascal UMAC™ Class-D technology
  • S/PDIF input/output
  • Configurable GPIO
  • ErP and Energy Star compliant
  • UL listed audio equipment
  • UREC™ universal power supply with PFC
  • 5 Year warranty

Specifications

SKU | Color

LBX-888-002 (PowerZone Connect 1502), LBX-888-014 (PowerZone Connect 1502 JPN)

Dimensions (WxHxD)

17.3" x 3.5" x 12.6" (439.42mm x 88.9mm x 320.04mm)

Weight

13.01 lbs. (5.9kg)

Channel Configuration

Lo-Z: 2x750W @2/4Ω Hi-Z: 1x 1200W @70v

Total System Power

1500 W

Output Power @ 2Ω

2 X 750 W (SE)

Output Power @ 4Ω

2 X 750 W (SE) 1 X 1500 W (BTL)

Output Power @ 8Ω

2 x 400 W (SE) 1 x 1500 W (BTL)

Output Power @ 70V

1 x 1200 W (BTL)

Output Power @ 100V

1 x 1500 W (BTL)

Powersharing

BTL

Copy All Specs
