Invisible Series
Ci4
Blaze Speakers
4" passive, 2-way, full-range loudspeaker
Key Features
- 4" woofer + 4" passive radiator. 1" silk dome tweeter. IP65 rated. Switchable limiting circuit for tweeter.
- Triangular ABS cabinet. Metal grille. Hidden cable connection. Mounts without brackets or with hidden sliders. Screw terminals.
- Couples together for 180° or 270° coverage.
- Placement: Indoors or outdoors, walls/ceilings including corners or hanging from ceiling.
- Compatible with Blaze Audio’s C8S and C12S subwoofers.
- Available in black or white.
Specifications
SKU | Color
BGM-888-007 (Black), BGM-888-008 (White)
HF Driver
1" silk dome tweeter
LF Driver
4" woofer + 4" passive radiator
Frequency Response (+/- 10db)
60 - 20 Hz
Sensitivity
86dB
Recommended Power Range
30 - 60 W / 8ohms
Enclosure
ABS
Dimensions (WxHxD)
7.48" x 15.75" x 5.71" (189.99mm x 400.05mm x 145.03mm)
Weight
5.95 lbs. (2.7kg)
Grille
Perforated Steel
Suspension Points
Indoors or outdoors, walls/ceilings incl. corners or hanging from ceiling, coupled.
Coverage (-6dB)
100° vertical / 100° horizontal
Maximum SPL (Peak)
111 dB
Horizontal Nominal Dispersion (-6 dB)
100 Degrees
