Invisible Series
PowerZone Connect Pro Amps
PowerZone Connect PRO 4000.4
Pre-Order
PowerZone Connect PRO 4000.4
Amplifiers
4000 W DSP-enabled Class D amplifier with 4 channels.
Unlock the full potential of your amplifier with built-in PowerZone Control DSP. Learn more.
Unlock the full potential of your amplifier with built-in PowerZone Control DSP. Learn more.
Key Features
- Full-rack, 2U form factor
- 4 x 1000 W at 70V/100V (4000 W total system power)
- Purpose-built for 70V/100V distributed audio with selectable Hi-Z/Lo-Z operation
- Full-matrix DSP configuration via PowerZone Control web app (built-in)
- Preloaded Sonance loudspeaker presets for optimized performance
- Control the system from the Wall-M controller or Sonance iOS app
- Configurable GPIO
- Control drivers and open API support for third-party control systems
- UL Listed audio equipment
- ErP and ENERGY STAR compliant
- Sonance 5-year warranty
Specifications
SKU
93805 (PowerZone Connect PRO 4000.4), 93817 (PowerZone Connect PRO 4000.4 UNI)
Dimensions (WxHxD)
17.3" x 3.5" x 16.3" (439.42mm x 88.9mm x 414.02mm)
Weight
25.6 lbs. (11.61kg)
Channel Configuration
Hi-Z: 4 x 1000W @70/100V Lo-Z: 4 x 1000W @8Ω
Total System Power
4000 W
Output Power @ 8 ohms
4 x 1000 W
Output Power @ 70V
4 x 1000 W
Output Power @ 100V
4 x 1000 W
Power Consumption
1400 W
Dante Compatibility
No
Rack Units
2U
