Invisible Series
PS-C41RT
Professional Series
The Sonance PS-C41RT In-Ceiling Speaker features a magnetically secured, bezel-less grille for easy installation and painting. Optional black and square grille adapters allow for customizable aesthetics. With a 4" polypropylene woofer for deep bass and a 0.75" soft dome tweeter for clear highs, it ensures exceptional audio performance.
Key Features
- Class-leading sensitivity & sonic performance
- Exceptional off-axis response
- Heavy duty voice coil for longevity and reliability
- Full-fidelity transformer for uncompromised tonality
- Consistent voicing across product range
- Bezel-less design for clean and minimalistic aesthetic
- Optional black grilles in round or square
- Magnetic grille retention for fast installation and removal
- Finger-adjustable selector tap
- One-step simplified painting process
Specifications
SKU | Color
45165 (White)
HF Driver
0.75" (19mm) Cloth Dome, Ferrofluid Cooled
LF Driver
4" (100mm) Polypropylene Cone, Butyl Rubber Surround
Frequency Response (+/- 10db)
70Hz-25khz
Frequency Response (+/- 3db)
95Hz - 20kHz
Power Handling (RMS)
60W program, 30W pink noise
Sensitivity
87dB (2.83V/1m)
Rated Maximum SPL
102dB @ 1 meter (3.3 feet), 108dB peak
Nominal Impedance (Ohms)
8 Ohms
Transformer Taps
70 V / 100 V: 25W, 12.5W, 6.3W 70 V: 3.2W
Dimensions (Diameter x D)
6.3" x 6.5" (160.02mm x 165.1mm)
Cut-Out Dimensions (Diameter)
5.875" (149.23mm)
Knockout
Side mounted 0.75" (19mm)
Weight
5 lbs. (2.27kg)
Input Connector
Four pin, Euroblock with loop output connections
Certifications
UL1480A; UL2043; EN 54; NFPA90A; NFPA70; CSA-C22.2 No.205; CSA C22.1
Suspension Points
One, on top surface
Maximum SPL (Peak)
108dB peak
